EMBEDDED Intel486™ PROCESSOR HARDWARE REFERENCE MANUAL
10-6
Another placement technique is called orthogonal arrangement, which requires more area than
the previous technique but produces similar results. This arrangement is shown in Figure 10-3.
These techniques reduce the electromagnetic interference (EMI), which is discussed in Section
10.3.3.1, “Electromagnetic Interference (EMI).”
Figure 10-3. Decoupling Capacitors
V
CC
GND
V
CC
Trace
GND
GNDGND
GND
GND
V
CC
Return or
GND Trace
†
Typical values should range between .01 µF and .1 µF
