Figure 10-11. Lattice Diagram
As an example, let the simple configuration shown in Figure 10-10 be assumed. Assume the fol-
lowing:
V
S
= 3.70 H(t)v
Z
0
= 75 ohms
Z
S
= 30 ohms
Z
L
= 100 ohms
The appropriate reflection coefficients can be calculated as follows:
source = (30–75)/(30+75)= 0.42857
load = (100–75)/(100+75)= 0.14286
X t
5t
pd
3t
pd
t
pd
t= 0
2t
pd
4t
pd
6t
pd
V
r
6
V
A
r
L
v
A
=
V
r
1
r
L
2
r
S
v
A
=
V
r
3
r
L
3
r
S
2
v
A
=
V
r
5
r
S
r
L
v
A
=
V
r
2
r
S
2
r
L
2
v
A
=
V
r
4
A B
