Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 145
Status Display:
NO BATTERY
REDUNDANCY
Tablet: No battery
redundancy!
Only one instead of two
batteries is detected in
the UAV.
This warning occurs only if
the motors are turned ON.
See as well “Battery warn-
ings of the UAV” on
page 149
Status Display:
LINK WEAK!
Tablet: Link weak!
One of the two data link
connections has failed.
Vibration on the CTR
Acoustic: “Link weak!”
Status Display:
LINK LOST!
Tablet: Link lost!
Data link connection is
lost.
Vibration on the CTR
Acoustic: “Link lost!”
Status Display:
GPS LOST!
Tablet: GPS signal
lost!
The GPS signal quality is
not sufficient.
Vibration on the CTR
Acoustic: “GPS lost!”
Status Display:
MOTOR FAILURE!
Tablet: Motor failure.
Land now!
There is an error with a
motor, a motor control-
ler or the motor bus.
Vibration on the CTR
Acoustic: “Motor failure.
Land now!”
Status Display:
JOYSTICK ERROR!
Tablet: Joystick
error. Land now!
The calibration of the
control sticks failed, e.g.
because the user was
pushing a joystick
during turn-on or
because something is
actually broken.
Vibration on the CTR
When the CTR is switched
ON, the joysticks are cali-
brated automatically.
Restart the CTR (take care
not to exert pressure on
any joystick) and see if the
warning is still active. If so,
the joystick electronics may
be broken. In this case
please get in touch with
Intel support.
Table 3.6: Possible Warnings (continued)
SHOWN TEXT REASON SIGNALS / NOTES

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
