Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 148
The following message is only shown if an Intel® High Resolution Imaging Payload is
mounted (see “Intel® High Resolution Imaging Payload” on page 48).
Status Display:
Payl. GPS not ready
The Intel® High Resolu-
tion Imaging Payload
does not receive a suffi-
cient GPS signal.
Possible workaround:
• Wait several minutes. It
might take some time
until the GPS receiver of
the payload has syn-
chronized.
• Move to a location with
better GPS reception.
• Power the UAV OFF and
then ON again.
The following messages are only shown in the notification area on the touchscreen
tablet.
Tablet battery
empty!
The battery of the
touchscreen tablet is
empty.
Shown only on tablet
Tablet battery
weak!
The battery of the
touchscreen tablet is
low.
Shown only on tablet
Gamepad requires
inspection license!
A gamepad for a second
camera operator was
connected but the fea-
ture, which is part of the
Inspection Package, is
not activated on the
UAV (see “THE INDE-
PENDENT CAMERA
CONTROL (ICC)” on
page 28.
Shown only on tablet
Table 3.6: Possible Warnings (continued)
SHOWN TEXT REASON SIGNALS / NOTES

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
