USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 147
Camera lens not
recognized!
Lens not recognized
(need to remove and re-
attach lens, or clean
lens contacts).
Shown only on tablet
Camera SD card
missing!
No SD card in payload
(card not inserted or not
properly inserted)
Shown only on tablet
Camera SD card
error!
The camera SD card
cannot be accessed.
Reasons could be, but
are not limited to:
• Write protect is
enabled on SD card
• Wrongly formatted
SD card
Shown only on tablet
Camera SD card
full!
Insufficient space on the
camera SD card (SD
card is full).
Shown only on tablet
Preparing Camera SD
card
SD card preparation in
progress (camera is
building a database
onto the card, not ready
yet for storing images/
videos).
Shown only on tablet
Camera temperature
high!
Camera high tempera-
ture warning (camera is
getting too hot, might
shut down soon).
Shown only on tablet
Payload SD card
missing!
No SD card in the pay-
load (card not inserted
or not properly
inserted).
Shown only on tablet
Table 3.6: Possible Warnings (continued)
SHOWN TEXT REASON SIGNALS / NOTES

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
