Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 158
Sensor
data cor-
rupt - criti-
cal!
GPS2COG
compen-
sated
position
data
corrupt!
Unusual behav-
ior
Restart sys-
tem or con-
tact support.
Sensor
data cor-
rupt - criti-
cal
Magnetic
incli-
nation/
decli-
nation data
corrupt!
Unusual behav-
ior
Restart sys-
tem or con-
tact support.
Sensor
data cor-
rupt - criti-
cal!
Data-fusion
input data
corrupt!
Unusual behav-
ior
Restart sys-
tem or con-
tact support.
Sensor
data cor-
rupt - usu-
ally not
critical due
to IMU
redun-
dancy
IMU1/IMU2/
IMU3 data
corrupt!
Any sensor value
out of range.
Usually none
Restart sys-
tem.
SD Card
No internal
SD card!
Internal SD card
cannot be used
(missing, full, file
system corrupt).
No internal data
logging (NAV1
data).
Insert / refor-
mat SD card.
SD Card
No user SD
card!
SD card in front
of central unit
faulty (missing,
full, file system
corrupt).
No external SD
data logging
(NAV2 data).
Insert / refor-
mat SD card;
use a different
SD card.
Table 3.13: AscTec Trinity Control Unit system warnings (continued)
CATEGOR
Y
WARNING/
ERROR
MEANING CONSEQUENC
E
POSSIBLE
FIXES

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
