Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 159
SD Card
FAT Write
to Sector
0???
Error with SD
card logger, pos-
sibly SD card
defective.
SD card logger
not working in
this flight.
Restart sys-
tem or con-
tact support if
it happens
repeatedly.
Navigation
Waypoint
sanity
check
failed
Waypoint trans-
mission problem.
No waypoint
navigation.
Resend way-
points / mis-
sion.
Navigation
Navi-gation
data
corrupt
Spline calculation
problem.
No waypoint
navigation.
Resend way-
points / mis-
sion.
Navigation
Tra-jectory
flight in
progress ->
CMD
ignored!
No reaction to
data transmis-
sion.
Resend way-
points / mis-
sion
Navigation
Can't fly
home - no
home
position
set!
ComeHome
does not work.
No GPS?
Navigation
N2U:
Trajectory
flight in
progress ->
CMD
ignored!
The user tried to
execute a survey
flight while a pre-
viously started
survey flight is
still ongoing. The
command sent to
the UAV will be
ignored and the
current survey
flight will be con-
tinued.
Abort the
ongoing sur-
vey flight and
send the new
flight parame-
ters again.
Table 3.13: AscTec Trinity Control Unit system warnings (continued)
CATEGOR
Y
WARNING/
ERROR
MEANING CONSEQUENC
E
POSSIBLE
FIXES

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
