Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 177
Selecting
Bounding
Box
and pushing
ENT opens the
following
screen.
This function
is only avail-
able in GPS-
Mode. Here
you can limit
the distance
and height of
the airspace
the Intel Fal-
con 8+ UAV is
flying in by
setting spe-
cific values.
The center of
this bounding
box is set to
the position of
the UAV where
Bounding
Box
is acti-
vated.
When the UAV
reaches the set
radius or alti-
tude it stops
and will not fly
any further.
By pushing the
RIGHT/ LEFT
arrow buttons
you can switch
between the
settings for
Radius and
Height and
Activate
and
Deactivate.
Pushing ENT
when selected
Radius or
Height high-
lights the field
behind. By
pushing the
RIGHT/ LEFT
arrow buttons
you can mod-
ify the selected
value.
Selecting
Activate/
Deactivate
activates/
deactivates
the function.
Pushing ENT
confirms the
selection and
brings you
back to the
Main Screen.
Table 4.1: Status Display Menu Structure (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
