USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 176
Selecting
Enter
FalconID
and pushing
ENT opens the
following
screen.
Here you can
connect to
another Intel®
Falcon™ 8+
UAV by enter-
ing the serial
number (ID) of
the respective
UAV (see
above) and
pushing ENT
(OK).
Pushing ESC
brings you
back to the
Main Screen.
Selecting
Format
User SD
and pushing
ENT opens the
following
screen.
This function
allows to for-
mat the User
SD card.
Pushing ENT
confirms the
formatting of
the User SD
card. The pro-
cess starts and
a progress bar
is shown.
Pushing ESC
cancels the
function and
brings you
back to the
Main Screen.
see “INTEL®
FALCON™ 8+
UAV FLIGHT
LOGS” on
page 91 for
further details.
Table 4.1: Status Display Menu Structure (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
