Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 219
Table 7.1: Technical Data
INTEL® FALCON™ 8+ UAV
TYPE V-Form Octocopter
SIZE 768 x 817 x 160 mm
ENGINES 8 electrical, brushless (sensorless)
motors with 125 W max. power each
ROTOR DIAMETER 20.32 cm (8 in)
NUMBER OF ROTORS 8
ROTOR WEIGHT 6 g (0.21 oz)
EMPTY WEIGHT 1.2 kg (2.65 lbs)
MAX. PAYLOAD WEIGHT (CAMERA AND
GIMBAL)
0.8 kg (1.76 lbs)
MAX. TAKE OFF WEIGHT 2.8 kg (6.17 lbs)
MAX. FLIGHT TIME WITHOUT
PAYLOAD*
26 min
MAX. FLIGHT TIME WITH MAX.
PAYLOAD WEIGHT*
16 min
MAX. FLIGHT TIME WITH A7R 16 min
MAX. FLIGHT TIME WITH INSPECTION
PAYLOAD
18 min
MAX. RANGE DATA LINK** 1 km (FCC version) (3281 feet)
850 m (CE version) (1640 feet)
MAX. SERVICE CEILING** 4000 m MSL (13123 feet)
MAX. ALTITUDE ABOVE GROUND
LEVEL**
Varies by country in which you operate
the UAV and requires you to check the
regulations that apply for your country
of operation
MAX. RANGE VIDEO LINK** 500 m (FCC and CE version) (1640 feet)
MAX. TOLERABLE WIND SPEED 12 m/s (26 mph) (GPS-Mode)
16 m/s (35 mph) (Height-Mode, Manual-
Mode)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
