Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 220
MAX. PRECIPITATION Not recommended to operate in any
form of precipitation
OPERATING TEMPERATURE -5 °C to 45 °C (23 °F to 113 °F)
SHORT TERM STORAGE
TEMPERATURE
(UP TO ONE MONTH)
-5 °C to 40 °C (23 °F to 104 °F)
LONG TERM STORAGE TEMPERATURE
(BEYOND ONE MONTH)
-5 °C to 25 °C (41 °F to 77 °F)
POWER SUPPLY 2 x Intel® Powerpack 4000 (redundant
setup)
NAVIGATION SENSORS
ASCTEC TRINITY CONTROL UNIT Triple redundant Inertial Measurement
Unit (IMU: barometer, compass, acceler-
ometers, gyroscopes)
GLOBAL NAVIGATION SATELLITE
SYSTEM (GNSS)
GPS and GLONASS
MAX. AIRSPEED
MANUAL-MODE 18 m/s (40 mph)
HEIGHT-MODE 18 m/s (40 mph)
GPS-MODE 4.5 m/s (10 mph) standard;
up to 10 m/s (22 mph) in mapping flights
MAX. CLIMB/SINK RATE
MANUAL-MODE 6 to 10 m/s (13 to 22 mph)
HEIGHT-MODE 3 m/s (6 mph)
GPS-MODE 3 m/s (6 mph)
MAX. TURN RATE
MANUAL-MODE / HEIGHT-MODE 115°/s
GPS-MODE 75°/s
MAX. PITCH AND ROLL ANGLES
MANUAL-MODE / HEIGHT-MODE 50°
GPS-MODE 45°
Table 7.1: Technical Data (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
