USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 221
WIRELESS COMMUNICATION
2 INDEPENDENT (DIVERSITY)
COMMAND AND CONTROL LINKS
2.4 GHz adaptive FHSS link with 100 mW
DIGITAL VIDEO LINK Low latency digital link.
5.1 Ghz to 5.8 GHz with up to 24 dBM /
250 mW (FCC compliant version).
5.1 Ghz to 5.8 GHz with up to 20 dBM /
100 mW (CE compliant version).
Resolution depending on payload up to
1080 p Full HD
INTEL® COCKPIT CONTROLLER (CTR)
DIMENSION (W X L X H) 320 x 380 x 135 mm (12.60 x 14.96 x
5.31 in)
WEIGHT 2.7 kg (5.95 lbs) (w/o battery)
3.1 kg (6.83 lbs) (with battery)
POWER SUPPLY 1 x Intel® Powerpack Battery
OPERATING TIME* 2 h
OPERATING TEMPERATURE -5 °C to 45 °C (23 °F to 113 °F)
SHORT TERM STORAGE
TEMPERATURE
(UP TO ONE MONTH)
-5 °C to 40 °C (23 °F to 104 °F)
LONG TERM STORAGE TEMPERATURE
(BEYOND ONE MONTH)
-5 °C to 25 °C (23 °F to 77 °F)
TOUCHSCREEN Size 8.3'', resolution 1980 x 1200 px
CONNECTIONS 4 x USB, 1 x HDMI
INTEL® POWERPACK BATTERY
TYPE Lithium Polymer (LiPo) 4S
CAPACITY 4000 mAh
VOLTAGE (NOMINAL) 14.8 V
ENERGY 59.2 Wh
OPERATING TEMPERATURE*** -5 °C to 40 °C (23 °F to 104 °F)
Table 7.1: Technical Data (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
