Page #222 background imageLoading...
Page #222 background image
USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 222
CHARGE TEMPERATURE Recommended: 10 °C to 30 °C (50 °F to
86 °F)
Max.: 5 °C to 40 °C (41 °F to 104 °F)
SHORT TERM STORAGE
TEMPERATURE
(UP TO ONE MONTH)
-5 °C to 40 °C (23 °F to 104 °F)
LONG TERM STORAGE TEMPERATURE
(BEYOND ONE MONTH)
18 °C to 28 °C (64 °F to 82 °F)
RECOMMENDED STORAGE VOLTAGE 3.7 V per cell
MAX CHARGING POWER 80 W
TYPICAL CYCLE LIFE 150 cycles
WEIGHT 398 g (14 oz) (tolerance +/- 5%)
AC ADAPTER (CHARGER FOR POWERPACK PP4000)
INPUT VOLTAGE 100-240 V, 50/60 Hz
MAXIMUM INPUT CURRENT 1.5 A
MAXIMUM OUTPUT CURRENT 4.74 A
OUTPUT VOLTAGE 19.0 V
* Data is based on having new batteries, fully charged, and at room temperature.
Data collection flights were performed at approximately 0 m (0 feet) above sea level
at outside temperature of approximately 15 °C (59° F), no wind, slow and steady
flight maneuvers, no hovering. All measurements done at International Standard
Atmosphere (ISA). Other factors may have influenced the results.
** The pilot is responsible for knowing and complying with all laws and regulations
applicable to the airspace in which the Intel® Falcon™ 8+ System is operated. Juris-
dictions have different safety rules related to authorization for flying unmanned air-
craft; flying near airports, manned aircraft, or people; operation within visual line of
sight; altitude limits and others. Data collection flights were performed at approxi-
mately 120 m (393 feet) above ground in GPS-Mode, drone facing away from pilot,
Cockpit antenna oriented exactly towards drone, no obstacles in-between line of
sight to drone and 400 m radius around drone and pilot, no external disturbance of
the 2.4 Ghz and 5.8 GHz bands. All measurements done at International Standard
Atmosphere (ISA). Other factors may have influenced the results.
Table 7.1: Technical Data (Continued)
