Intel FALCON 8+ User Manual

USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2018 Intel Corporation. All rights reserved 223
*** The maximum temperature for the Intel® Powerpack depends on the system and
the configuration it is used with:
• The Intel® Falcon™ 8+ combined with the Intel® Cockpit Controller - operating
temperature is 45°C (113°F)
• The Intel® Falcon™ 8+ without a payload attached and two fully charged
batteries inserted - maximum operating temperature is 45°C (113°F)
• The Intel® Falcon™ 8+ with payload attached - maximum operating
temperature is 40°C (104°F).
Because of the necessary higher current, the batteries will produce more
heat.
Table 7.1: Technical Data (Continued)

Intel FALCON 8+ Specifications

General

Type	Octocopter
Easy to use	Yes
Product color	Black, Yellow
Maximum speed	16 m/s
Frequency band	2.4 GHz
Number of rotors	8 rotors
Maximum flight time	26 min
Maximum weight capacity	2.8 kg
Maximum operating distance	1000 m
Maximum pitch angular velocity	50 °/sec
Operating temperature (T-T)	-5 - 40 °C
Transmitter power consumption	100 mW
Built-in processor	-
Moving control functions	Backward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Depth	817 mm
Width	768 mm
Height	160 mm
Weight	1200 g
Rotor diameter	203.2 mm
