Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide 87
5 Technical Reference
Cable Routing
When you add or remove components from your server chassis, make sure your cables are
routed correctly before reinstalling the chassis cover. Use caution to make sure no cables
or wires are pinched and that the airflow from the fans is not blocked.
Power Supply Specifications
The power supply specifications for your Intel
®
Entry Server Chassis SC5299-E will
depend upon the configuration of chassis you purchased. Four power supply
configurations are available:
• 550-W PFC fixed power supply (DP configuration)
• 650-W PFC redundant power supply (BRP configuration)
• 670-W PFC fixed power supply (WS configuration)
550-W Single Power Supply Input Voltages
• 100-127V at 50/60 Hz; 140 V
rms
max.
• 200-240V at 50/60 Hz; 264 V
rms
max.
550-W Single Power Supply Output Current
The following table lists the total amperage available from the power subsystem for each
voltage. Ensure that your loads do not exceed the combined total wattage of 550 Watts.
Table 4. 550-W Power Supply Output Capability
Voltage
Maximum
Current
+3.3 V 24 A
+5.0 V 24 A
+5 V Standby 3 A
+12.0 V1 40 A
-12.0 V 0.5 A
+12 V2 16 A
