Intel SC5299WS

Rack Mount Kit Install Instructions (optional)
Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide 77
6. Remove any PCI add-in boards. Remove the PCI card guide by pressing in on the blue
tabs (see letter “A” in the following figure) and pulling the PCI card guide outward
(see letter “B”).
Figure 99. Removing PCI Card Guide
TP02001
A
B
