Server Chassis Features
Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide 3
Component Identification
Front View Components
Figure 2. Front View Components (with Front Bezel Assembly)
A. 5.25-in Device Drive Bays
B. Front Panel
C. Drive Bay Access Door
D. Door Lock
E. Front Panel USB Ports
TP02345
B
C
A
D
E
