Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide 1
1 Server Chassis Features
This chapter describes the main features of the Intel
®
Entry Server Chassis SC5299-E.
The location of important chassis components and connections, as well as a description of
LED identification, are also presented.
Figure 1. Front View of Intel
®
Entry Server Chassis SC5299-E
The Intel
®
Entry Server Chassis SC5299-E is a 5.2U pedestal
1
server chassis and is
available in three configurations: DP (dual-processor), WS (workstation), and BRP (base
redundant power). The chassis is designed to support the Intel
®
Server Boards
S5000XVN, S5000PSL, S5000XSL and S5000VSA. The type of server board supported
is dependent upon the configuration purchased. See Table 1 for a list of the Intel
®
server
boards that are supported by each server chassis configuration.
AF000307
1. The Intel
®
Entry Server Chassis SC5299-E can be configured as a rack-mountable server chassis when outfitted
with the optional Rack Mount Kit (order code APP3RACKIT).
Table 1. Breakdown of Intel
®
Entry Server Chassis SC5299-E Configurations
Intel
®
Entry Server Chassis
SC5299-E
Configuration
Intel
®
Server Boards Supported
1
DP (Dual-processor) Intel
®
Server Boards S5000VSA, S5000XSL and S5000PSL
WS (Workstation) Intel
®
Server Board S5000XVN
BRP (Base Redundant Power) Intel
®
Server Boards S5000VSA, S5000XSL and S5000PSL
NOTES:
1. For updated server board support, go to http://support.intel.com/support/motherboards/server/
chassis/sc5299-e/.
