88 Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide
670-W Single Power Supply Input Voltages
• 100-127V at 50/60 Hz; 12 A
rms
max.
• 200-240V at 50/60 Hz; 7 A
rms
max.
670-W Single Power Supply Output Voltages
The following table lists the total amperage available from the power subsystem for each
voltage. Ensure that your loads do not exceed the combined total wattage of 670 Watts.
650-W Single Power Supply Input Voltages
• 100-127V at 50/60 Hz; 9.63 A
rms
max.
• 200-240V at 50/60 Hz; 4.82 A
rms
max.
650-W Single Power Supply Output Voltages
The following table lists the total amperage available from the power subsystem for each
voltage. Ensure that your loads do not exceed the combined total wattage of 650 Watts.
Table 5. 670-W Power Supply Output Capability
Voltage
Maximum
Current
+3.3 V 24 A
+5.0 V 30 A
+5 V Standby 3.0 A
+12 V1 16 A
+12 V2 16 A
+12 V3 16 A
+12 V4 16 A
-12.0 V 0.5 A
Table 6. 650-W Power Supply Output Capability
Voltage
Maximum
Current
+3.3 V 24 A
+5.0 V 30 A
+5 V Standby 3.0 A
-12.0 V 0.3 A
12 V1 16 A
12 V2 16 A
12 V3 16 A
