Hardware Installations and Upgrades
54 Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide
Installing Feet for a Pedestal-configured Chassis
Note: Do not install feet on your Intel
®
Entry Server Chassis SC5299-E if it is to be installed in
a rack. Only install feet on a pedestal-configured chassis.
1. Observe the safety and ESD precautions listed in Appendix A, “Safety Information”.
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Lay the chassis down on its right side.
4. Insert rubber foot into chassis hole (see letter “A” in the following figure). Secure foot
to chassis by inserting a pin through the rubber foot (see letter “B”). Repeat process
for remaining feet.
Figure 70. Installing Feet on Chassis
5. Put chassis in the upright position.
6. Reconnect all peripheral devices and the AC power cable to the server. Power up the
server.
TP01709
A
B
