Hardware Installations and Upgrades
14 Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide
Installing the Front Bezel Assembly
1. Line up the three clips on the right-side of the front bezel assembly with the
corresponding slots on the right-side of the chassis (see letter “A” in the following
figure). Engage the clips with the slots (see letter “B”). Rotate the left side of the the
front bezel assembly towards the chassis (see letter “C”). Snap the two bezel tabs into
the corresponding recesses at the left edge of the chassis front panel (see letter “D”).
Figure 12. Installing the Front Bezel Assembly
2. Reinstall the left side cover. For instructions, see “Installing the Left Side Cover”.
3. Reconnect all peripheral devices and the AC power cable. Power up the server.
TP02035
D
D
A
A
A
C
A
B
