Hardware Installations and Upgrades
28 Intel® Entry Server Chassis SC5299-E DP/WS/BRP User Guide
15. Re-install the PCI card guide. Insert tabs on left side of PCI card guide into slots in
chassis (see letter “A” in the following figure). Swing PCI card guide into chassis
until right-side blue tabs snap into place (see letter “B”).
Figure 31. Re-installing PCI Card Guide
16. Re-install any PCI add-in cards that were removed. For instructions, see “Installing
PCI Add-in Boards”.
17. Re-install the front bezel assembly. For instructions, see “Installing the Front Bezel
Assembly”
18. Re-install the left side cover. For instructions, see “Installing the Left Side Cover”
19. Plug all peripheral devices and the AC power cable back into the server. Power up the
server.
Removing a Fixed Hard Drive
Caution: Fixed drives are NOT hot swappable. Before removing or replacing the drive, you must
first take the server out of service, turn off all peripheral devices connected to the system,
turn off the system by pressing the power button, and unplug the AC power cord from the
system or wall outlet.
1. Observe the safety and ESD precautions listed in Appendix A, “Safety Information”.
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the left side cover. For instructions, see “Removing the Left Side Cover”.
4. Remove the front bezel assembly. For instructions, see “Removing and Installing the
Front Bezel Assembly”.
TP01735
A
B
