Interroll MultiControl User Manual

Configure MultiControl
6 Operating and Programming
➢ To select a function, remove the magnet when the corresponding LED is lit..
Two seconds after removing the magnet, the selection is accepted. During this time, the
"Ready" and "Com" LEDs and the LED belonging to the selection flash. If a second
selection belongs to this function, the LED of the previous selection flashes for approx.
Seven seconds.
➢ To select this second selection, hold the magnet back to the magnetic sensor after two
seconds.
A running light starts in the LED bar on the right side of the MultiControl.
Function
Selection
Selection No.
LED
2: Select sensors
PNP Normally Closed
1
Sensor 3
NPN Normally Closed
2
I/O 3
PNP Normally Open
3
RD 3
NPN Normally Open
4
RD 4
3: Select bus type
EtherCAT
1
Sensor 3
PROFINET
2
I/O 3
EtherNet/IP
3
RD 3
4: Perform teach-in
procedure
Read motors
1
I/O 3
Start teach-in
2
RD 4
Cancel teach-in
3
Sensor 3
6: Reset MultiControl to
factory settings
Confirmation
I/O 4
➢ To accept the second selection, remove the magnet when the corresponding LED is lit. The
selection is accepted five seconds after removing the magnet.
If the EtherCAT bus type is selected, the user interface can no longer be used after
the restart since this bus type does not support it.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
