Process data
88 Operating and Programming
PII, Process Image „Universal Full“
Byte
Bit
Category
Description
Type
Comment
0
.0
Sensors
Sensor 1
BOOL
High = Sensor active
(input type and polarity
can be configured)
0
.1
Sensors
Sensor 2
BOOL
0
.2
Sensors
Sensor 3
BOOL
0
.3
Sensors
Sensor 4
BOOL
0
.4
Sensors
Sensor 5
BOOL
Start sensor Zone 1
0
.5
Sensors
Sensor 6
BOOL
Reserve
0
.6
Sensors
Sensor 7
BOOL
0
.7
Sensors
Sensor 8
BOOL
1
.0
Digital I/O
PLC Input
PLC Output
Handshakes:
In Up
In Down
Out Up
Out Down
I/O 1
BOOL
Logical state, voltage
level depends on
configuration (NPN/PNP;
polarity) State at input,
high/low = sensor
blocked/not blocked
1
.1
Digital I/O
PLC Input
PLC Output
Handshakes:
In Up
In Down
Out Up
Out Down
I/O 2
BOOL
1
.2
Digital I/O
PLC Input
PLC Output
Handshakes:
In Up
In Down
Out Up
Out Down
I/O 3
BOOL
