Interroll MultiControl User Manual

Description of the control programs
Operating and Programming 31
5.3 ZPA Transfer In
With the "ZPA Transfer In" program, conveyed items can be fed into the conveyor line from up
to two additional infeeds.
The conveyed items are forwarded downstream according to the direction of upstream, left or
right. The signals for the direction selection are set by a PLC.
If an infeed is free in the "automatic merge" setting, the remaining infeeds are automatically
handled alternately in order to avoid jams (see table "merge prioritization").
In "Motorsettings" set motor 1 to "counterclockwise".

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
