Interroll MultiControl User Manual

Process data
110 Operating and Programming
PIO, Process Image „Control Mode“
Byte
Bit
Category
Description
Type
Comment
0
.0
Control Inputs
Overwrite
Control Input 1
BOOL
Meaning depends on the
selected state table (such as
‘stop zone’ for the state table
Zone Control)
0
.1
Control Inputs
Overwrite
Control Input 2
BOOL
0
.2
Control Inputs
Overwrite
Control Input 3
BOOL
0
.3
Control Inputs
Overwrite
Control Input 4
BOOL
0
.4
Control Inputs
Overwrite
Control Input 5
BOOL
0
.5
Control Inputs
Overwrite
Control Input 6
BOOL
0
.6
Control Inputs
Overwrite
Control Input 7
BOOL
0
.7
Control Inputs
Overwrite
Control Input 8
BOOL

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
