Interroll MultiControl User Manual

Configure MultiControl
Operating and Programming 7
LED displays when using the magnetic sensor
When the magnetic sensor detects the magnet, the "Fault" LED lights up permanently. If the
setting via the magnetic sensor is activated, the "Ready" and "Com" LEDs also flash at 1 Hz.
LED
State
Definition
Sensor 1
On
Setting function 1: Cancel
I/O 1
On
Setting function 2: Select Sensors
I/O 1 +
Sensor 3
On
Selection 1 for setting function 2: Sensors PNP Normally
Closed
I/O 1 +
I/O 3
On
Selection 2 for setting function 2: Sensors NPN Normally
Closed
I/O 1 +
RD 3
On
Selection 3 for setting function 2: Sensors PNP Normally
Open
I/O 1 +
RD 4
On
Selection 4 for setting function 2: Sensors NPN Normally
Open
RD 1
On
Setting function 3: Select bus type
RD 1 +
Sensor 3
On
Selection 1 for setting function 3: EtherCAT
RD 1 +
I/O 3
On
Selection 2 for setting function 3: PROFINET
RD 1 +
RD 3
On
Selection 3 for setting function 3: EtherNet/IP
RD 2
On
Setting function 4: Teach-in procedure
RD 2 +
Sensor 3
On
Selection 1 for setting function 4: Read motors
RD 2 +
I/O 3
On
Selection 2 for setting function 4: Start teach-in
RD 2 +
RD 3
On
Selection 3 for setting function 4: Cancel teach-in

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
