Interroll MultiControl User Manual

Configure MultiControl
8 Operating and Programming
LED
State
Definition
Sensor 2
On
Setting function 5: Switch on/off the LED displays of the
sensors / I/O
I/O 2
On
Setting function 6: Reset MultiControl to factory settings
I/O 2 +
I/O 4
On
Confirm setting function 6: Reset MultiControl to factory
settings
Sensor 3
Flashes 1 Hz
EtherCAT stack is being loaded
I/O 3
Flashes 1 Hz
PROFINAT stack is being loaded
RD 3
Flashes 1 Hz
EtherNet/IP stack is being loaded
Together with the following displays the LED "Ready" and "Com" flash with 2 Hz, the LED "Fault"
is off.
LED
State
Definition
RD 1
Sensor 3
On
Flashes 2 Hz
Selection "EtherCAT" active, magnetic sensor not activated
(anymore)
RD 1
I/O 3
On
Flashes 2 Hz
Selection "PROFINET" active, magnetic sensor not
activated (anymore)
RD 1
RD 3
On
Flashes 2 Hz
Selection "EtherNet / IP" active, magnetic sensor not
activated (anymore)
I/O 2
I/O 4
On
Flashes 2 Hz
Confirmation of setting function 6: Reset selected, magnetic
sensor not pressed (anymore)

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
