Interroll MultiControl User Manual

Configure MultiControl
18 Operating and Programming
Inputs and Outputs
SDO-Index: 0x4800
Sub-index
Description
Data type
Access
Comment
1
Type PNP
Sensor 1
BOOL
R/W
True = PNP-Sensor
FALSE = NPN-Sensor
2
Type PNP
Sensor 2
BOOL
R/W
3
Type PNP
Sensor 3
BOOL
R/W
4
Type PNP
Sensor 4
BOOL
R/W
5
Type PNP
AUX 1
BOOL
R/W
True = PNP-Sensor
FALSE = NPN-Sensor
Attention: This also affects
the use of AUX as output!
6
Type PNP
AUX 2
BOOL
R/W
7
Type PNP
AUX 3
BOOL
R/W
8
Type PNP
AUX 4
BOOL
R/W
9
Polarity Pos
Sensor 1
BOOL
R/W
True = Positive Polarity
Sensor (Physical „1”
corresponds to logical „1”)
False = Negative Polarity
Sensor (Physical „0”
corresponds to logical „1”)
A
Polarity Pos
Sensor 2
BOOL
R/W
B
Polarity Pos
Sensor 3
BOOL
R/W
C
Polarity Pos
Sensor 4
BOOL
R/W
D
Polarity Pos
AUX 1
BOOL
R/W
E
Polarity Pos
AUX 2
BOOL
R/W
F
Polarity Pos
AUX 3
BOOL
R/W

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
