Interroll MultiControl User Manual

Process data
Operating and Programming 79
System Status
The fourth area of the process image of the inputs contains the following status information of the
system:
• The current level of both supply voltages
• The temperature
• The runtime since the last restart
Description
Byte
Data type
Comment
Voltage 1
16
INT
[mV] Supply voltage „Power Motor“
Voltage 2
18
INT
[mV] Supply voltage „Power Logic +
Sensors“
Temperature
20
INT
[dC] Temperature of the MultiControl
Runtime
22
INT
[s] Time since last restart
Additional signals
The last part of the process image of the inputs is subdivided into five subsections:
• Control Inputs
• Control Outputs
• Handshake-Signals
• Zone status
• Global signals
These input signals have no meaning for the use of MultiControl as I/O device.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
