Interroll MultiControl User Manual

Description of the control programs
Operating and Programming 47
Handover (Handshake-Signals)
The exchange of the required information for the transport of conveyed items between the
MultiControl and an external control takes place via handshake signals.
Out Left = Signal from MultiControl Merge is free
In Left = Signal to MultiControl Transfer conveyed items from the left
Out Right = Signal from MultiControl Merge is free
In Right = Signal to MultiControl Transfer conveyed items from the right
PII - Handshake Signals
ID
Zone
PLC-Reference (Read)
Byte
Bit
Out Left
Signal: Merge is free
I: 29
6
Out Right
Signal: Merge is free
I: 29
7
PIO - Handshake Signals
ID
Zone
PLC-Reference (Read)
Byte
Bit
In Left
Signal: Transfer in from Left
Q: 8
2
In Right
Signal: Transfer in from Right
Q: 8
3

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
