Configuration options
4 Operating and Programming
3 Configuration options
To commission the MultiControl, it must first be configured. This can be done in different ways:
• All settings can be configured via a web-based user interface on a computer connected to
the MultiControl (see "Interroll MultiControl Instruction Manual")
• Using the magnetic sensor, the sensors, the bus type and the LED displays can be
configured directly on the MultiControl, as well as the MultiControl can be tested,
automatically configured or reset to the factory settings (see "The Magnetic Sensor", page
5)
• Service Data Objects (SDO) written by a higher-level controller can be used to configure
all settings except the bus type (see "Service Data Objects (SDO)", page 9)
• The station name, IP configuration and connection settings can be changed via a PLC
development environment
