Interroll MultiControl User Manual

Configure MultiControl
Operating and Programming 13
Bus parameter
SDO-Index 0x4600
Sub-index
Description
Data type
Access
Comment
1
Bus Type
USINT
R
Used Bus type:
1 = EtherCAT
2 = PROFINET
3 = EtherNet/IP
2
IP Configuration
Mode
USINT
R/W
Configuration mode of the
address:
1 = Static
2 = BOOTP
3 = DHCP
3
IP Address
UDINT
R/W
Own IP address
4
IP Network Mask
UDINT
R/W
Subnet mask
5
IP Gateway
Address
UDINT
R/W
IP-Address Default
Gateway
6
IP Address DNS
1
UDINT
R/W
IP-Address Domain Name
Server #1
7
IP Address DNS
2
UDINT
R/W
IP-Address Domain Name
Server #2
8
IP Host Name
STRING
R/W
IP Host Name
9
IP Domain Name
STRING
R/W
IP Domain Name
A
ACD Enable
BOOL
R/W
Identification of address
conflicts (EtherNet/IP)
B
Quick Start up
Enable
BOOL
R/W
QuickStart (PROFINET)

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
