Interroll MultiControl User Manual

Description of the control programs
Operating and Programming 23
5.1 ZPA Single Release
For Single Release the removal is done in individual zones („ZPA Single Release 1 Zone“ to „ZPA
Single Release 4 Zone“).
Free RollerDrive connections can be used as slave motors according to the table (PII Motor
States).
Timer
ID
Description
Default [ms]
T1
Connection monitoring
200
T2
Internal conveyed items monitoring
4000
T3
Follow-up time RollerDrive
5000
T4
Error reset
1000
The parameter "Timer 1 - Connection monitoring" should not be changed.
In addition to the explanations of the control programs, the corresponding process
images are listed below.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
