Interroll MultiControl User Manual

Description of the control programs
Operating and Programming 35
Direction selection
Up
Left
Right
Decision
Automatic merge
Free
Free
Free
No transport
Free
Free
Blocked
From right to down
Free
Blocked
Free
From left to own
Free
Blocked
Blocked
In order from left / right
to down
Blocked
Free
Free
From up to down
Blocked
Free
Blocked
In order from up / right
to down
Blocked
Blocked
Free
In order from up / left to
down
Blocked
Blocked
Blocked
In order from up / left /
right to down
Handover (Handshake-Signals)
The exchange of the required information for the transport of conveyed items between the
MultiControl and an external control takes place via handshake signals.
Out Left = Signal from MultiControl Transfer is free
In Left = Signal to MultiControl Receive conveyed items from the left to transfer
Out Right = Signal from MultiControl Transfer is free
In Right = Signal to MultiControl Receive conveyed items from the right to transfer
PII - Handshake Signals
ID
Zone
PLC-Reference (Read)
Byte
Bit
Out Left
Signal: Transfer free
I: 29
6
Out Right
Signal: Transfer free
I: 29
7

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
