Interroll MultiControl User Manual

I/O configuration
118 Operating and Programming
9 I/O configuration
No.
Value
Description
Comment
1
0
None
I/O not used
2
1
PLC Input
Input signal to PLC
3
2
PLC Output
Output signal from PLC
4
15
Sensor 5
Additional inputs can also be found
at the corresponding point in the
process image.
5
16
Sensor 6
6
17
Sensor 7
7
18
Sensor 8
8
21
Control Input 1
9
22
Control Input 2
10
23
Control Input 3
11
24
Control Input 4
12
25
Control Input 5
13
26
Control Input 6
14
27
Control Input 7
15
28
Control Input 8
16
31
Control Output 1
17
32
Control Output 2
18
33
Control Output 3
19
34
Control Output 4
20
35
Control Output 5
21
36
Control Output 6
22
37
Control Output 7
23
38
Control Output 8
24
41
Handshake InUp
25
42
Handshake InDown

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
