Process data
114 Operating and Programming
PII, Process Image „I/O Mode Tiny“
Byte
Bit
Category
Description
Type
Comment
0
.0
Sensors
Sensor 1
BOOL
High = Sensor active (input
type and polarity can be
configured)
0
.1
Sensors
Sensor 2
BOOL
0
.2
Sensors
Sensor 3
BOOL
0
.3
Sensors
Sensor 4
BOOL
0
.4
Sensors
Sensor 5
BOOL
0
.5
Sensors
Sensor 6
BOOL
0
.6
Sensors
Sensor 7
BOOL
0
.7
Sensors
Sensor 8
BOOL
1
.0
Digital I/O
I/O 1
BOOL
High = Auxiliary
input/output 1 active (type
and polarity can be
configured)
1
.1
Digital I/O
I/O 2
BOOL
1
.2
Digital I/O
I/O 3
BOOL
1
.3
Digital I/O
I/O 4
BOOL
1
.4
Digital I/O
Reserve
BOOL
Reserve
1
.5
Digital I/O
Reserve
BOOL
1
.6
Digital I/O
Reserve
BOOL
1
.7
Digital I/O
Reserve
BOOL
2
.0
Motors
MotorError 1
BOOL
High = Error Motor
2
.1
Motors
MotorOn 1
BOOL
High = Motor on
2
.2
Motors
MotorV2 1
BOOL
High = Speed V2 selected
2
.3
Motors
MotorDir 1
BOOL
High = Reverse main
direction
2
.4
Motors
MotorError 2
BOOL
High = Error Motor
2
.5
Motors
MotorOn 2
BOOL
High = Motor on
2
.6
Motors
MotorV2 2
BOOL
High = Speed V2 selected
2
.7
Motors
MotorDir 2
BOOL
High = Reverse main
direction
