Interroll MultiControl User Manual

Description of the control programs
24 Operating and Programming
PLC references according to process image "Universal Full" (see process data)
PII - Sensors 1 - 5
ID
1 Zone
2 Zones
3 Zones
4 Zones
PLC-Reference (Read)
Byte
Bit
B1
Sensor Zone 1
Sensor Zone 1
Sensor Zone 1
Sensor Zone 1
I: 0
0
B2
Not used
Sensor Zone 2
Sensor Zone 2
Sensor Zone 2
I: 0
1
B3
Not used
Not used
Sensor Zone 3
Sensor Zone 3
I: 0
2
B4
Not used
Not used
Not used
Sensor Zone 4
I: 0
3
B5
Start Sensor
Zone 1
Start Sensor
Zone 1
Start Sensor
Zone 1
Start Sensor
Zone 1
I: 0
4
PII - Motor States (Speed 1 - 4)
ID
1 Zone
2 Zones
3 Zones
4 Zones
PLC-Reference (Read)
Byte
M1
Motor Zone 1
Motor Zone 1
Motor Zone 1
Motor Zone 1
I: 3
M2
Not used
Motor Zone 2
Motor Zone 2
Motor Zone 2
I: 4
M3
Not used
Not used
Motor Zone 3
Motor Zone 3
I: 5
M4
Not used
Not used
Not used
Motor Zone 4
I: 6
PIO - Control Inputs Overwrite (Control Input 1 - 4)
ID
1 Zone
2 Zones
3 Zones
4 Zones
PLC-Reference (Write)
Byte
Bit
CI1
Stop Zone 1
Stop Zone 1
Stop Zone 1
Stop Zone 1
Q: 5
0
CI2
Not used
Stop Zone 2
Stop Zone 2
Stop Zone 2
Q: 5
1
CI3
Not used
Not used
Stop Zone 3
Stop Zone 3
Q: 5
2
CI4
Not used
Not used
Not used
Stop Zone 4
Q: 5
3

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
