Page #43 background imageLoading...
Page #43 background image
Description of the control programs
38 Operating and Programming
Timer
ID
Description
Default [ms]
T1
Connection monitoring
100
T2
Not used
2000
T3
Error reset
1000
T4
Internal conveyed items monitoring
4000
The parameter "Timer 1 - Connection monitoring" should not be changed.
PLC references according to process image "Universal Full" (see process data)
PII - Sensors 1 - 4
ID
Description
Connection
MultiControl
Type
PLC-Reference (Read)
Byte
Bit
B1
Sensor Vertical Zero Position
Sensor Zone 1
PNP / positive
I: 0
0
B2
Sensor Outfeed Left
Sensor Zone 2
PNP / positive
I: 0
1
B3
Sensor Outfeed Right
Sensor Zone 3
PNP / positive
I: 0
2
B4
Sensor Trailing Edge Query
Sensor Zone 4
PNP / positive
I: 0
3
Settings for transfer variants
Transfer variant
Connection
MultiControl
Type
Up to Left / Right / Down
-
-
Up to Left / Down
Sensor 3 (B3)
PNP / negative *
Up to Right / Down
Sensor 2 (B2)
PNP / negative *
Up to Left
Sensor 3 (B3)
PNP / negative *
Up to Right
Sensor 2 (B2)
PNP / negative *
Up to Left / Right
-
-
*Setting in the Web server or via SDO, no sensor connected
