Interroll MultiControl User Manual

Configure MultiControl
Operating and Programming 19
Sub-index
Description
Data type
Access
Comment
10
Polarity Pos
AUX 4
BOOL
R/W
11
IO Function
AUX 1
USINT
R/W
Select function for
AUX-I/O
12
IO Function
AUX 2
USINT
R/W
13
IO Function
AUX 3
USINT
R/W
14
IO Function
AUX 4
USINT
R/W
15
IO Diagnose
LED On
BOOL
R/W
TRUE = LED on
FALSE = LED off
Application module
SDO-Index: 0x4900
Sub-index
Description
Data type
Access
Comment
1
State Table ID
UINT
R/W
2
Timer 1
UINT
R/W
Application program I/O-
Device: no meaning
Other application
programs: Adjustment
according to description
3
Timer 2
UINT
R/W
4
Timer 3
UINT
R/W
5
Timer 4
UINT
R/W
