Interroll MultiControl User Manual

Description of the service functions
Operating and Programming 67
Abort the Teach-in procedure
1. Via web browser in the menu Service / Teach-In / Abort
2. With the magnetic key:
➢ To abort the Teach-in procedure, the magnetic sensor must be actuated. When the
magnetic sensor detects the magnetic key, the "Fault" LED lights up permanently.
➢ After one second, the LED bar on the left side of the MultiControl starts a running
light.
➢ As soon as the LED "RD 2" lights up, remove the magnetic key and wait until the
running light of the right LED bar starts.
➢ Re-actuate the magnetic sensor.
➢ If the "Sensor 3" LED is lit, remove the magnetic key.
Configuring the sensors
If the sensor settings are changed and the ZPA program is desired, this must be set via web
browser.
If sensors do not match the factory settings of the MultiControl, it is possible to change them with
the help of the magnetic key:
➢ Actuate the magnetic sensor. When the magnetic sensor detects the magnetic key, the
"Fault" LED lights up permanently.
➢ After one second, the LED bar on the left side of the MultiControl starts a running light.
➢ As soon as the LED "I/O 1" lights up, remove the magnetic key and wait until the running
light of the right LED bar starts.
➢ Re-actuate the magnetic sensor.
➢ If the LED of the desired sensor type is lit, remove the magnetic key.
Sensor-Type
LED MultiControl
PNP Normally Closed
Sensor 3
NPN Normally Closed
I/O 3
PNP Normally Open
RD 3
NPN Normally Open
RD 4

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
