Interroll MultiControl User Manual

Description of the control programs
30 Operating and Programming
PIO - Handshake Signals
ID
Zone
Digital I/O Setting
PLC-Reference
(Write)
Byte
Bit
In Up
Signal transfer in to first zone
Handshake In Up
Q: 8
0
In Down
Signal transfer out of last zone
Handshake In Down
Q: 8
1
The signal for discharging the conveyed items must be active until the conveyed
items no longer block the zone sensor. If the signal is previously deactivated, the
conveyed material stops in the blocked zone sensor.
In Train Release, when the transfer out signal is reset, initialization is done in the
mode „Single Release“. Then it is changed to „Train Release“ mode.
The signal for transferring goods in is an adequate impulse. The conveyed items are
conveyed to the zone sensor. The length of the impulse must be at last 100 ms.

Interroll MultiControl Specifications

General

Power Supply	24 VDC
Rated Voltage	24 VDC
Storage Temperature	-20 °C to +70 °C
Communication Protocols	Ethernet/IP, PROFINET, EtherCAT, CANOpen
Number of Channels	4
Weight	0.5 kg
