Process data
94 Operating and Programming
Byte
Bit
Category
Description
Type
Comment
8
.0
Handshake
Signals
Overwrite
UpIn
BOOL
Start first zone
8
.1
Handshake
Signals
Overwrite
DownIn
BOOL
Start last zone
8
.2
Handshake
Signals
Overwrite
LeftIn
BOOL
Start left
8
.3
Handshake
Signals
Overwrite
RightIn
BOOL
Start right
8
.4
Handshake
Signals
Overwrite
UpOut
BOOL
End of first zone
8
.5
Handshake
Signals
Overwrite
DownOut
BOOL
End of last zone
8
.6
Handshake
Signals
Overwrite
LeftOut
BOOL
End left
8
.7
Handshake
Signals
Overwrite
RightOut
BOOL
End right
