Invacare Storm 3 - 4 Service plan (1 x annually)

Storm³
Service Manual
Page 12 As at:07.03.02
4 Service plan (1x annually)
Component Check Remedy Chapter
:
"
Armrests and
side panels
• Armrest damage and
fastening
• Side panel damage and
fixing
⇒ Tighten screws, replace
padding
⇒ Tighten screws, replace
side panels
12.3
12.3
Seat unit / seat
angle
adjustment
• Cushion
• Check seat angle
adjustment
⇒ Replace covers /
upholstery
⇒ Replace parts
12
Backrest unit
mechanical
Backrest unit
electrical
• Damage and seams
• Fixings
• check cabling
• Check function
⇒ Replace parts
⇒ Tighten screws
⇒ Replace cable or motor if
necessary
13
13.3
Frame (chassis)
/ battery strap
• Check fixings, welded
seams and battery strap
⇒ Tighten screws, replace
components
8.1
Wheel
suspension and
wheels
• Check drive wheels for
tight fit and side play
• Check steering wheels for
tight fit, float and side play
• Check castor wheel forks
• Check tyres
⇒ Adjust, replace wheel
hubs
⇒ Replace wheels, wheel
fork or wheel bearings
⇒ Replace
⇒ Fit new
9.16
9.1.10
9.1.1
9.1.5
9.1.3
9.1.9
Drive units,
disengager
• Check functions in drive
and push modes
• Check disengager
⇒ Replace motor if
necessary
⇒ Tighten screws / nuts,
adjust or replace if
necessary
8.3
8.4.1
Footrests
• Check welded seams,
interlocking, screws,
footplates
⇒ Tighten, replace
15
Electrical
footrests
• Check cabling
• Check contacts
• Check functions
⇒ Replace cable if
necessary
14.5.1
Lighting
• Check cabling ⇒ Replace bulbs or cables if
necessary
10
