Service Manual
Storm³
As at: 07.03.02 Page 47
1.15 4 F60106 HEXAGON CAP NUT M6 SELF-LOCKING
11.2.2 Replacing the tray
• Unscrew the Phillips screw (1) out of the tray attachment.
• Remove tray and replace.
• After fitting the new tray, remove the protective film.
11.2.3 ACS operation for attendant (switchable)
Pos Qty. Item No./Pcs. Item Description
1 1 6001425 ACS OPERATION FOR ATTENDANT SWITCHABLE
1.1 1 Z183001A BELLOWS FOR ACS JOYSTICK; BLACK
1.2 1 P10304 ACS JOYSTICK FOR STD REMOTE
1.3 1 P41105 SOCKET FOR BUS CABLE
1.4 1 GME61927 FIXING CLASP FOR ACS BUS PLUG
1.5 1 P40120 DRIVE LEVER KNOB FOR ACS REM. ATT.
SWITCHABLE
