Invacare Storm 3 - 7 Module Composition; Variations

Service Manual
Storm³
As at: 07.03.02 Page 17
9 or 10 x blink
Faulty data transmission
between modules
- Check drive unit /
battery chapt.
8.3.2 / 9.2
11 x blink
Motors overloaded /
overheated
• Switch remote on
and off / wait if
necessary
-
12 x blink
Module used has
compatibility problems
• Remove incorrect
module
Check drive unit /
battery chapt.
8.3.2 / 9.3.1
7 Module composition / variations
The Storm³ can be supplied the following options from start of production:
• Batteries (chapt.9.2)
# 70 Ah
• Brake (chapt.8.5)
• Drive wheels / steering wheels (chapt. 9.1.6. 9.1)
# 3.00 - 8 drive wheels (pneumatic, puncture-proof)
# 3.00 - 6 castor wheels (pneumatic, puncture-proof)
• Lighting (chapt. 10)
• Remote and accessories (chapt. 11)
# ACS REM24 SC
# ACS operation for attendant (switchable)
# ACS tray control
# centre joystick swingaway
# chin control
# G80 I
# remote holder height-adjustable / swingaway
• Backrest elements (chapt. 13)
# backrest adjustment manual
# backrest adjustment electrical
• Headrest (chapt. 13.5)
• Legrests/footrests (chapt. 14. 15)
