Invacare Storm 3 - Cane Holder (Standard)

Service Manual
Storm³
As at: 07.03.02 Page 91
16.2 Cane holder (standard)
Pos Qty. Item No./Pcs. Item Description
- 1 SP1422844 CANE HOLDER STD. ASSY.
1 2 1423187 ADHESIVE TAPE
2 2 1423176 SKIFFY NAIL
3 1 1423158 SPEED CLIP
4 1 1420493 BELT
5 2 F60107 HEXAGON CAP NUT M6 SELF-LOCKING
6 1 F20111 HEXAGON NUT M5 SELF-LOCKING
7 2 F00002 HEXAGON NUT M8 SELF-LOCKING
8 1 D50050 MACHINE SCREW WITH ALLEN KEY HEAD M5 X 25
9 1 D00199 HEXAGON BOLT M8 X 40
10 2 D90187 CHEESE HEAD SCREW WITH ALLEN KEY HEAD M6 X
20
11 1 5007160 CANE HOLDER SHELL 117 X 61
12 1 G10106 WASHER 5.3 X 15 X 1.6
13 2 1422890 WASHER 5.3 DIN 125
14 4 G00115 WASHER 6.4 X 12.5 X 1.6
15 4 G00107 WASHER 8.4 X 17 X 1.6
