Storm³
Service Manual
Page 82 As at:07.03.02
14.5 Footrest hanger (ADE) with electrical height adjustment
Pos Qty. Item No./Pcs. Item Description
- 1 SP1422569 FOOTREST HANGER RH ELECTRICAL HEIGHT-
ADJUSTABLE ASSY.
- 1 SP1422570 FOOTREST HANGER LH ELECTRICAL HEIGHT-
ADJUSTABLE. ASSY.
1 1 SPZ151006 LIFT MOTOR WITH PCB PREASSEMBLED
2 2 P22414 CABLE BINDER L=142 MM
3 3 F20111 HEXAGON NUT M5 SELF-LOCKING
4 2 F00002 HEXAGON NUT M8 SELF-LOCKING
5 3 D50050 MACHINE SCREW WITH ALLEN KEY HEAD M5 X 25
6 1 D50047 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 12
7 1 D50051 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 16
8 1 D08120 HEXAGON BOLT M6 X 16
9 2 D50052 MACHINE SCREW WITH ALLEN KEY HEAD M8 X 40
