Storm³
Service Manual
Page 80 As at:07.03.02
- 1 SP1422568 FOOTREST HANGER LH 80° MANUAL HEIGHT-
ADJUSTABLE ASSY.
1 3 F20111 HEXAGON NUT M5 SELF-LOCKING
2 2 F00002 HEXAGON NUT M8 SELF-LOCKING
3 3 D50050 MACHINE SCREW WITH ALLEN KEY HEAD M5 X 25
4 1 D50047 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 12
5 2 D50051 MACHINE SCREW WITH ALLEN KEY HEAD M6 X 16
6 2 D50052 MACHINE SCREW WITH ALLEN KEY HEAD M8 X 40
7 1 Z174139 ADP BLANK
8 3 Z173189.99 NUT M6 SP-14
- 1 SP1423195 MOUNTING SET RELEASE LEVER FOR BST 80° MAN.
HV
9 1 Z174113.99 LOCKING ROD
10 1 Z174112 RELEASE LEVER (AD)
11 1 Z173177 CLASP LEVER
12 1 Z174134 SLIDING CYLINDER
13 1 J10093 STRAIGHT PIN RD. 8 X 30. DIN-7
14 3 J10094 STRAIGHT PIN RD. 8 X 36. DIN-7
15 1 Z173178 TENSION SPRING
16 1 N12196 PRESSURE SPRING
17 1 Z174135.89 MOTOR RECEPTACLE
18 1 Z174111 LEG SUPPORT SHELL (AD) LH
19 1 Z174110 LEG SUPPORT SHELL (AD) RH
20 1 Z174162 KNEE CUSHION (ADM) LH
21 1 Z174172 KNEE CUSHION (ADM) RH
22 1 SPZ174130 ADM ADJUSTMENT ASSY.
23 1 Z173207-9005 FOOTREST HANGER RH 80° MANUAL HEIGHT-
ADJUSTABLE
24 1 SPZ174164 CALF PLATE PREASSEMBLED
14.4.1 Replacing the ADM adjustment
