Storm³
Service Manual
Page 72 As at:07.03.02
• Remove headrest shell (see page 71, chapt. 13.5.1).
• Loosen the hand screw (1) on the headrest attachment.
• Pull the headrest arm out and replace.
13.5.3 Replacing the headrest attachment
• Loosen the hand screw (1).
• Pull the headrest out.
• Lever the plastic caps (2) off with a screwdriver.
• Unscrew the Phillips screws beneath this.
• Remove the headrest attachment and replace.
Reassembly takes place in the reverse order.
14 Footrest Hanger
The service work described in the following chapter relates to both the right-hand and left-hand
footrest hanger. The footrest hanger settings can be individually matched to the user. These
settings should therefore be retained when carrying out service work.
